Description
| Item | Specification |
|---|---|
| Pole No. | 1-2-3 |
| Rated Voltage | AC 240/415V |
| Rated Current (A) | 1, 2, 3, 4, 6, 8, 10, 13, 16, 20, 25, 32, 40, 50, 63 |
| Tripping Curve | B, C, D |
| Rated Breaking Capacity (Icu) |
4500A |
| Rated Frequency | 50/60Hz |
| Rated Impulse Withstand Voltage | 4.5kV |
| Electro-Mechanical Endurance | 10000 |
| Contact Position Indication | — |
| Connection Terminal | Screw terminal / Pillar terminal with clamp |
| Connection Capacity | Rigid conductor up to 25mm² |
| Fastening Torque | 2.5 Nm |
| Installation | On symmetrical DIN rail 35mm / Panel mounting |
