Description
|
Model |
RUMC31BD |
RUMC31JD |
|
product or component type |
11-pin Plug-in relay |
11-pin Plug-in relay |
|
Device short name |
RUM |
RUM |
|
Contacts type and composition |
3 C/O |
3 C/O |
|
[Uc] control circuit voltage |
24 V DC |
12 V DC |
|
[Ithe] conventional enclosed thermal current |
10 A at -40…55 °C |
10 A at -40…55 °C |
|
Status LED |
Without |
Without |
|
Control type |
Lockable test button |
Lockable test button |
|
Utilisation coefficient |
20% |
20% |
|
Shape of pin |
Cylindrical |
Cylindrical |
|
[Ui] rated insulation voltage |
250 V conforming to IEC |
250 V conforming to IEC |
|
300 V conforming to CSA |
300 V conforming to CSA |
|
|
300 V conforming to UL |
300 V conforming to UL |
|
|
[Uimp] rated impulse withstand voltage |
4 kV (1.2/50 µs) |
4 kV (1.2/50 µs) |
|
Contacts material |
AgNi |
AgNi |
|
[Ie] rated operational current |
10 A at 277 V AC conforming to UL |
10 A at 277 V AC conforming to UL |
|
10 A at 30 V DC conforming to UL |
10 A at 30 V DC conforming to UL |
|
|
10 A at 277 V AC (same polarity) conforming to CSA |
10 A at 277 V AC (same polarity) conforming to CSA |
|
|
10 A at 30 V DC conforming to CSA |
10 A at 30 V DC conforming to CSA |
|
|
5 A at 250 V AC (NC) conforming to IEC |
5 A at 250 V AC (NC) conforming to IEC |
|
|
5 A at 28 V DC (NC) conforming to IEC |
5 A at 28 V DC (NC) conforming to IEC |
|
|
10 A at 250 V AC (NO) conforming to IEC |
10 A at 250 V AC (NO) conforming to IEC |
|
|
10 A at 28 V DC (NO) conforming to IEC |
10 A at 28 V DC (NO) conforming to IEC |
|
|
Maximum switching voltage |
250 V conforming to IEC |
250 V conforming to IEC |
|
Resistive rated load |
10 A at 250 V AC |
10 A at 250 V AC |
|
10 A at 28 V DC |
10 A at 28 V DC |
|
|
Maximum switching capacity |
2500 VA/280 W |
2500 VA/280 W |
|
Minimum switching capacity |
170 mW at 10 mA, 17 V |
170 mW at 10 mA, 17 V |
|
Operating rate |
<= 18000 cycles/hour no-load |
<= 18000 cycles/hour no-load |
|
<= 1200 cycles/hour under load |
<= 1200 cycles/hour under load |
|
|
Mechanical durability |
5000000 cycles |
5000000 cycles |
|
Electrical durability |
100000 cycles for resistive load |
100000 cycles for resistive load |
|
Average coil consumption in W |
1.4 W |
1.4 W |
|
Drop-out voltage threshold |
>= 0.1 Uc DC |
>= 0.1 Uc DC |
|
Operate time |
20 ms at nominal voltage |
20 ms at nominal voltage |
|
Release time |
20 ms at nominal voltage |
20 ms at nominal voltage |
|
Average coil resistance |
470 Ohm at 20 °C +/- 15 % |
120 Ohm at 20 °C +/- 15 % |
|
Rated operational voltage limits |
19.2…26.4 V DC |
9.6…13.2 V DC |
|
Protection category |
RT I |
RT I |
|
Test levels |
Level A group mounting |
Level A group mounting |
|
Safety reliability data |
B10d = 100000 |
B10d = 100000 |
|
Operating position |
Any position |
Any position |
