Description
|
Model |
RXM4AB1P7 |
|
Product type |
14 - Pin Plug-in relay |
|
Contacts type and composition |
4 C/O |
|
[Uc] control circuit voltage |
230 V AC 50/60 Hz |
|
Status LED |
Without |
|
Control type |
Lockable test button |
|
Utilisation coefficient |
20% |
|
Shape of pin |
Flat |
|
[Ui] rated insulation voltage |
250 V conforming to IEC |
|
300 V conforming to CSA |
|
|
300 V conforming to UL |
|
|
[Uimp] rated impulse withstand voltage |
2.5 kV during 1.2/50 µs |
|
Contacts material |
AgNi |
|
[Ie] rated operational current |
3 A at 28 V (DC) NC conforming to IEC |
|
3 A at 250 V (AC) NC conforming to IEC |
|
|
6 A at 28 V (DC) NO conforming to IEC |
|
|
6 A at 250 V (AC) NO conforming to IEC |
|
|
6 A at 277 V (AC) conforming to UL |
|
|
8 A at 30 V (DC) conforming to UL |
|
|
Continuous output current |
5:00 AM |
|
Maximum switching voltage |
250 V conforming to IEC |
|
resistive rated load |
6 A at 250 V AC |
|
6 A at 28 V DC |
|
|
Maximum switching capacity |
1500 VA/168 W |
|
Minimum switching capacity |
170 mW at 10 mA, 17 V |
|
Operating rate |
<= 1200 cycles/hour under load |
|
<= 18000 cycles/hour no-load |
|
|
Mechanical durability |
10000000 cycles |
|
Electrical durability |
100000 cycles for resistive load |
|
average coil consumption in VA |
1.2 at 60 Hz |
|
Average consumption |
1.2 VA at 60 Hz |
|
Drop-out voltage threshold |
>= 0.15 Uc |
|
operate time |
20 ms |
|
release time |
20 ms |
|
average coil resistance |
15000 Ohm at 20 °C +/- 15 % |
|
Rated operational voltage limits |
184…253 V AC |
|
Safety reliability data |
B10d = 100000 |
|
Protection category |
RT I |
|
Test levels |
Level A group mounting |
|
Operating position |
Any position |
|
CAD overall height |
79 mm |
|
CAD overall depth |
78.45 mm |
|
Net weight |
0.037 kg |
