| Main |
| Range |
New Unica |
| Product or component type |
Data socket |
| Device application |
Communication |
| Device presentation |
Mechanism |
| Colour tint |
White (RAL 9003) |
| Data socket type |
RJ45 8 contact(s) Cat.6 < 250 MHz |
| Provided equipment |
Protective flap |
| Label holder |
| Complementary |
| Communication network type |
1000BASE-TX |
| Communication port protocol |
ATM 1200 Mbps |
| Number of modules |
1 module |
| Socket number |
1 |
| Type of footprint |
Infraplus |
| Connector type |
S-One |
| Cable shielding type |
U/UTP |
| Organization of wire |
Unshielded twisted pair |
| Connections - terminals |
Click |
| Device mounting |
Flush |
| Fixing mode |
Clip-in |
| Installation direction |
Straight |
| Material |
Thermoplastic ABS-UV stabilised: central plate |
| Depth |
40.5 mm |
| Width |
22.5 mm |
| height |
45 mm |
| Embedding depth |
40.5 mm |
| Resistance to chemical agents |
Resistant to alcohol (70 %) |
| Resistant to alcohol (96 %) |
| Resistant to A-Lactic Acid |
| Resistant to diluted quaternary ammonium |
| Resistant to diluted bleach |
| Resistant to diluted ammonia |
| Resistant to soapy water |
| Resistant to crystal cleaner |
| Resistant to hydrogen peroxide 10 volumes |
| Resistant to hexane |
| Environment |
| IP degree of protection |
IP20 |
| IK degree of protection |
IK01 |
| Ambient air temperature for operation |
-25…55 °C |
| Ambient air temperature for storage |
|
