Description
|
Main |
|
|
Range |
Miluz |
|
Product or component type |
Dimmer |
|
Fixing mode |
By 2 screws |
|
Complementary |
|
|
Device mounting |
Flush |
|
device presentation |
Mechanism |
|
Switch function |
Dimmer |
|
Dimmer control |
Rotary |
|
Type of packing |
Plastic bag |
|
Dimmer application |
Light |
|
Protection type |
Short-circuit and overload protection with automatic reset |
|
Associated fuse rating |
2 A |
|
Load type |
Dimmable LED |
|
230 V AC halogen lamp |
|
|
230 V AC incandescent lamp |
|
|
[Ue] rated operational voltage |
220...240 V AC |
|
Power range |
4...250 W |
|
Material |
PC: screw |
|
Network frequency |
47...53 Hz |
|
Surface finish |
PVC coated |
|
Number of modules |
1 module |
|
Connections - terminals |
2 screw terminals |
|
Cable cross section |
2.5 mm² |
|
1.5 mm² |
|
|
Cable stiffness |
Flexible |
|
Wire stripping length |
10 mm |
|
height |
48.8 mm |
|
Width |
44.8 mm |
|
Depth |
44.8 mm |
|
Embedding depth |
39.3 mm |
|
Environment |
|
|
product certifications |
IEC |
|
IP degree of protection |
IP20 |
