| Range |
Miluz |
| Product or component type |
Socket-outlet |
| fixing mode |
Click-in |
| Device presentation |
Basic element with full cover plate |
| Device mounting |
Flush |
| Outlet standard deviation |
Universal |
| Type of packing |
Plastic bag |
| [In] rated current |
16 A |
| [Ue] rated operational voltage |
250 V AC |
| Material |
PC (polycarbonate): cover |
| PC (polycarbonate): base |
| Surface finish |
Glossy |
| Conductor material |
Copper |
| Number of modules |
1 module |
| Connections - terminals |
Screw clamp terminal |
| Cable stiffness |
Flexible |
| Rigid |
| Solid stranded |
| Number of cables |
2 |
| Cable cross section |
1.5 mm² |
| 2.5 mm² |
| 4.0 mm² |
| Wire stripping length |
12 mm |
| Height * Width * Depth |
44.75 * 22.3 * 36.35 mm |
| Net weight |
0.0247 kg |
| Standards |
IEC 60884-1 |
| Product certifications |
IEC |
| IP degree of protection |
IP20 |
